Cofi Trs1020 Ignition Transformer
Cofi Trs1020 Ignition Transformer

Cofi Trs1020 Ignition Transformer

Price 2800 INR/ Piece

MOQ : 50 Pieces

Cofi Trs1020 Ignition Transformer Specification

  • Condition
  • New, New
  • Output
  • Secondary: 2 x 5 kV, 20 mA, 2 x 5 kV, 20 mA
  • Heat Efficiency
  • High
  • Pressure
  • Standard atmospheric
  • Life Span
  • Long Functional Life (Rated for continuous duty)
  • Capacity
  • 20 VA
  • Voltage
  • Primary: 230 V AC, 50/60 Hz
  • Temperature
  • -20C to +60C
  • Style
  • Compact/Encapsulated, Encapsulated
  • Fuel Type
  • Oil/Gas, Oil/Gas
  • Material
  • High grade Insulation, Metal housing
  • Part Type
  • Ignition Transformer, Ignition Transformer
  • Dimension (L*W*H)
  • 138 x 80 x 95 mm
  • Function
  • Ignition voltage supply for burners
  • Protection Level
  • IP00
  • Duty Cycle
  • 100% ED
  • Mounting Type
  • Surface mount
  • Insulation Class
  • Class F
  • Secondary Peak Voltage
  • 10 kV (each output)
  • Weight
  • Approx. 1.2 kg
  • Primary Current
  • 0.18 A



About Cofi Trs1020 Ignition Transformer

"COFI TRS1020 Ignition Transformer available with Preci-Tech India and are in Good quality with ready stock. Moreover, these can be acquired from us at market reasonable price which differ According to Model & Accessories.

Details:Available in different range...

  • oil transformer
  • gas transformer
  • o/p - 2x4 kv
  • o/p - 2x5 kv
  • COFI TRS820
  • And many more
