C7027A Honeywell Flame Sensor

Name: C7027A Honeywell Flame Sensor
Brand: SAPTAM CORPORATION
Price: 9000 INR
Availability: InStock

Price 9000 INR/ Piece

Get a Price/Quote

MOQ : 50 Pieces

C7027A Honeywell Flame Sensor Specification

Output
UV flame signal, Signal to flame safeguard control

Condition
New, New

Voltage
Normal: 300 V RMS max

Temperature
Operating: -40C to +215C (-40F to +419F)

Capacity
Suitable for single and multi-burner applications

Life Span
Long service life (>1,000,000 cycles)

Pressure
Applicable for low to moderate pressure burners, Normal atmospheric

Fuel Type
Natural Gas, Propane, Liquefied Petroleum, Gas/Oil

Style
Compact flame rod, Tube Style

Material
Glass and Metal

Part Type
Flame Sensor, Flame Sensor

Dimension (L*W*H)
Approximately 6 (Length) x 1 (Diameter)

Function
Detects presence of flame in gas fired burners

Sensor Type
Ultraviolet (UV)

Application
Commercial/industrial burners, flame safeguard systems

Connector Type
1/2" NPT

Weight
Approx. 60 g

Cable Length
1.2 m (4 ft)

Response Time
Less than 1 second

Approval
UL Recognized, CSA Certified

Mounting
Threaded

Replacement For
C7027A1005, C7027A1047

About C7027A Honeywell Flame Sensor

The C7027A, C7035A, C7044A and C7927A Flame Detectors detect the ultraviolet radiation emitted by combustion flames. The flame detectors are used with Honeywell flame safeguard controls to provide flame supervision for gas, oil, or combination gas-oil burners.

flame detector for use with flame safeguard controls with ultraviolet amplifiers. ... The C7044 UV sensor tube is enclosed in a stainless steel housing.
